Leica Rangemaster CRF PRO

SKU: LS40547

Leica Rangemaster CRF PRO
Leica Rangemaster CRF PRO
Leica Rangemaster CRF PRO
Leica Rangemaster CRF PRO

Our Price

$1,690.00

$1,690.00


Loading

500

169000

Shipping Quote

When will I receive it?

About this product

Leica Rangemaster CRF Pro

Compact format. Highest precision. Maximum accuracy.

The new Leica Rangemaster CRF Pro is our most powerful compact rangefinder. It’s the ultimate specialist for long-range shooters, alpine hunters, and hunters abroad. Exceptional ballistics performance and a range of up to 2,600 meters leave nothing to be desired. Thanks to the integrated ballistics program Applied Ballistics UltralightTM, the Leica Rangemaster CRF Pro can rapidly calculate the equivalent horizontal range, as well as the correction values for holdover, units, and clicks – even in very complex shooting situations and adverse weather conditions.

The essentials:

  • First time in a compact Leica Rangemaster: the advanced Applied Ballistics software for maximum precision
  • Fully upgradeable to AB Elite.
  • Extremely precise laser rangefinding from 10 to 2,600 meters, in just 0.3 seconds.
  • Weather Station on board for live environmental calibrations.
  • Leading optical quality for unique observation moments and precise target acquisition.
  • Geo Mapping enabled to drop pin location virtually for enhanced tracking, scouting, and recovery.
  • Enhanced Bluetooth connectivity with: Leica Ballistics, Leica Protrack, Kestrel, Basemap, and GoogleMaps.

Superior optical quality for ideal observations.

The Leica Rangemaster CRF Pro boasts an extremely powerful optical system for rapid target acquisition and precise identification of game. Hunters also benefit from the extraordinarily wide field of view. First-class workmanship, proven materials, extremely efficient reduction of stray light and reflections, as well as specially-coated prism surfaces feature the Leica CRF Pro. By delivering rich detail, sharpness, contrast, and color fidelity, the optics of the Rangemaster CRF Pro enable unique observation moments.

Precise laser rangefinding.

The Leica Rangemaster CRF Pro is Leica's most powerful compact monocular rangefinder. Perfectly positioned, easy-grip controls and intuitive user guidance let the hunter take aim quickly and reliably. By measuring the transit time of a laser beam emitted and reflected at the speed of light, the distance to the target is calculated with minimal tolerances. In less than 0.3 seconds, the on-board computer outputs the exact result, which proven LED display technology makes easy to read, even in very bright conditions. Distances between 10 and 200 meters are measured in 0.1 meter increments – ideal for bow hunters who require highest precision at shorter distances. The maximum range of the CRF Pro is 2,600 meters.

Applied Ballistics inside.

The Leica Rangemaster CRF Pro is the first monocular laser rangefinder to be equipped with the powerful ballistics software Applied Ballistics UltralightTM. This offers the ultimate point-of-impact correction for a safe shot – even at longer ranges. Regardless of the weather, backlighting, or challenging uphill or downhill angle shots, highly sensitive sensors measure ambient parameters such as temperature, air pressure, and inclination angle. Based on these values, the ballistics correction values such as holdover, units, or clicks up to a range of 800 meters are output directly on the rangefinder display. An optional upgrade to Applied Ballistics Elite® unlocks all ballistics features up to a maximum range of 2,600 meters.

Compact, handy format.

The Rangemaster CRF Pro is the ideal companion on all hunting trips and won’t hamper strenuous stalks. The handy, particularly grippy housing of this compact Leica rangefinder is made of lightweight and durable fiberglass-reinforced plastic in hunter’s olive green. Only a few functions are assigned to each of the two control buttons. Thanks to one-hand operation, it can be removed from a trouser pocket and put to use in a single smooth motion. Leica product designers focused closely on the essentials: simple, intuitive operation with the greatest possible functionality – encased in an extremely rugged housing.

Advanced connectivity solutions.

Featuring Bluetooth® connectivity and a link to the Leica Ballistics App on the smartphone, the Leica Rangemaster CRF Pro is completely at home in the digital world. Ballistics data of the rifle and ammunition can be adjusted on the mobile phone; settings and personal ballistics profiles can be transmitted to the Rangemaster. Data from a Garmin smartwatch or, for example, crosswind info from a Kestrel® weather meter can also be imported via Bluetooth® – or entered manually.

GPS tracking with Leica ProTrack (LPT™)

It can be difficult to find a shot game animal, especially in the mountains or other difficult terrain. The direct route may be impossible because you need to traverse a valley, or you may have lost your overview of the area. A wireless connection to the Leica Ballistics App puts a GPS tracking system at your fingertips. Leica ProTrack (LPTTM) determines the GPS coordinates based on the last measured distance, marks this point on a digital map (e.g. via Basemap®) and thus makes it easier to check your target or locate the game animal after the shot.

Specifications

Specifications

Feature Specification
Designation Leica Rangemaster CRF PRO
Type No. 4032
Order No. 40 547
Magnification 7x
Lens Diameter 24 mm
Exit Pupil 3.4 mm
Field of View at 1,000 m / 1,000 yds 115 m / 405 ft
Close-up Range 10 m / approx. 16 ft
Diopter Adjustment +/- 3.5 dpt
Lens Coating High Durable Coating (HDC™) and hydrophobic Aqua-Dura® coating on outer lenses
Prism System Roof prisms with phase-correction coating P40
Eyecups Turn-down rubber eyecups
Display LED display with 4 digits, automatic brightness control
Laser Type Eye-safe, invisible Class 1 laser acc. to EN and FDA
Measuring Time Approx. 0.3 s (max.)
Measuring Accuracy +/- 0.5 m at 10-200 m; +/- 0.5 yds at 10-219 yds
+/- 1.0 m at 200-1,000 m; +/- 1.0 yds at 219-1,093 yds
+/- 0.5 % beyond 1,000 m/yards
Switching Option: Meters/Yards Yes
Range 10 to approx. 2,600 m / 2,800 yds
Measuring Range for Equivalent Horizontal Range (EHR) 10 m to approx. 2,600 m / 2,800 yds
Measurement Logic Optimum target
Correction Output with Applied Ballistics® Ultralite (Standard) Max. 800 m / 875 yds
Correction Output with Applied Ballistics® Elite (Upgrade) Max. 2,600 m / 2,800 yds
Measuring Methods Scan mode / Single measurement
Ballistics Calculator Yes
Output "Equivalent Horizontal Range" (EHR) Yes
Output "Unit Correction" for Elevation and Lateral Correction Yes
Output "Click Correction" for Elevation and Lateral Correction Yes
On-Board Wind Correction Yes
Upgrade to Applied Ballistics® Elite Yes, with creation of customised ballistic profiles
GPS Guidance LPT™ (Leica ProTrack)
Wireless Connection Bluetooth®
External App Connection BaseMap®, Leica Ballistics App, Kestrel®, Garmin®
Sensors Temperature, air pressure, inclination, compass
Waterproof Rating Waterproof to 1 m / 3.2 ft
Battery 1 x 3 V / Lithium type CR2
Battery Life Approx. 1,700 measurements at 20 °C / 68 °F*
Housing Material Polyamide ABS plastic
Dimensions (L x H x W) 113 x 78 x 35 mm
Weight Approx. 185 g

What's in the Box

  • Leica Rangemaster CRF PRO
  • Cordura case
  • Neoprene carrying strap
  • Battery (CR2)
